Boiler Makeup Water

Boiler Makeup Water

Scale buildup inside boiler tubes is one of the leading causes of boiler failure. A deposit just 1/16-inch thick on heat transfer surfaces increases fuel consumption by approximately 12%, and at higher pressures even thin scale can cause tube rupture. The American Boiler Manufacturers Association (ABMA) publishes water quality guidelines for steam boilers by operating pressure — at 600 psig, total dissolved solids in the feedwater must be below 150 ppm, with hardness at zero and silica below 0.3 ppm.

AMPAC USA designs reverse osmosis systems specifically for boiler feedwater applications. Systems are sized by steam output requirements, blowdown rate, and local makeup water TDS to ensure the RO permeate consistently meets the target water quality specification. Where operating pressure demands it, a mixed-bed deionization polisher is added downstream to achieve resistivity above 1 megohm-cm.

Pre-treatment is matched to the source water: softening for hard groundwater, carbon filtration for chlorinated municipal supply, and antiscalant dosing to protect membranes. All systems include a conductivity meter on the permeate line so operators can monitor feedwater quality continuously and catch membrane degradation before it affects boiler performance.

Contact Us

Emergency Portable Reverse Osmosis 20,000 GPD, AP20K-LX-C by AMPAC USA is suitable to serve commercial & residential units. To order it today, call 909-548-4900.

View details

Industrial Reverse Osmosis 8,000 GPD, AP8000-LX by AMPAC USA is ready to be shipped, highly automated and value for money.

View details

Industrial Turnkey Brackish Water Reverse Osmosis 80,000 GPD by AMPAC USA. At low cost. Call 909-548-4900.

View details

Commercial Turnkey Brackish Reverse Osmosis 6,000 GPD, AP6000-LX by AMPAC USA gets rid of brackish water. For instant delivery of this model, call 909-548-4900.

View details

Industrial Reverse Osmosis 80,000 GPD, AP80K-LX by AMPAC USA serves industrial water needs of large industrial units. Call 909-548-4900 for early shipping at low cost.

View details

Industrial Reverse Osmosis 60,000 GPD, AP60K-LX by AMPAC USA is more affordable and highly cost effective. It can be customized too.

View details

Industrial Reverse Osmosis 6,000 GPD, AP6000-SM-LX by AMPAC USA eliminates impurities and TDS from the water.

View details

Industrial Reverse Osmosis 40,000 GPD, AP40K-LX by AMPAC USA serves giant water needs of communities, industries, and commercial units.

View details

Industrial Reverse Osmosis 30,000 GPD, AP30K-LX by AMPAC USA is awesome for large water needs of individuals and industries.

View details

Industrial Reverse Osmosis 25,000 GPD, AP25K-LX by AMPAC USA is ideal for residential, commercial and industrial use. Call 909-548-4900 to get it shipped fast.

View details

Industrial Reverse Osmosis 20,000 GPD, AP20K-LX by AMPAC USA is suitable to serve commercial units and residential communities.

View details

Industrial Reverse Osmosis 12,000 GPD, AP12K-LX by AMPAC USA is fully automated and works seamlessly with minimal human supervision.

View details

Industrial Reverse Osmosis 100,000 GPD, AP100K-LX by AMPAC USA meets the water needs of different industries perfectly. To buy it today, call 909-548-4900.

View details
  • Description
  • Applications
  • Features and Benefits

Description

Reverse Osmosis Purification Process for Boilers

Boilers require the water to be pure by removing Total Suspended solids (TSS) Iron, Silica, Hardness and Chlorides, Reverse Osmosis is the best and the most economical solution

When this system would be applied to the boiler feed by removing the total dissolved solids from the feed water the boiler would work at a faster pace and hence the total time taken in completing boiler operations would be drastically reduced.

Pure reverse osmosis water is fully capable of increasing the efficiency of both, Standard Boilers and High Pressure Boilers. Not only the purifier would feed the boiler with clean water, but also reduces the boiler blowdown requirements. When you purchase a quality water purification system from AMPAC you would surely lower maintenance and operations costs pertaining to the boiler.

If you are skeptical about whether you should choose us to design a custom made water purification system or not then you shouldn’t worry anymore. We have a large team of highly educated and exceptionally experienced team of engineers who are capable of designing a water purification system in accordance with the type of boiler you use on a regular basis.

Our experts would visit your site personally, notice the specifications of your boiler and judge the quality of the makeup water you are using before suggesting a water purification system that would be best for you. We would also custom build the system for you from scratch so that you can be assured that there is no other system that would fit so perfectly with your boilers. Stop thinking and start the process of purchasing a Water Purification System for boilers from us.

Have a look at some of the key Reverse Osmosis Water Purification Systems created by AMPAC to get an idea of which one would suit your needs.
